TF Overrunning Clutch Tool
Jump to page : 1
Now viewing page 1 [50 messages per page]		View previous thread :: View next thread
   Forward Look Technical Discussions -> Transmission and Rear AxleMessage format

57chizler
Posted 2013-12-22 4:44 PM (#417875)
Subject: TF Overrunning Clutch Tool



Expert

Posts: 3835
2000100050010010010025
Location: NorCal
I had a graphic image, with dimensions, of the tool for the iron TF rollers but Windows 7 won't show it...anybody got one they can post.
Top of the page Bottom of the page
jimntempe
Posted 2013-12-22 5:53 PM (#417888 - in reply to #417875)
Subject: Re: TF Overrunning Clutch Tool



Expert

Posts: 2312
2000100100100
Location: Arizona		post/send the one you have and it can probably be fixed so it will open.
Top of the page Bottom of the page
ttotired
Posted 2013-12-22 6:47 PM (#417894 - in reply to #417875)
Subject: Re: TF Overrunning Clutch Tool



Expert 5K+

Posts: 8449
50002000100010010010010025
Location: Perth Australia		I was trying to think what tool you meant

Got it now

I dont have that tool, but you are talking about the part with those rectangular springs and the rollers (I think)

I had a hard time trying to work out how to put the stupid things in, then it occured to me that they can be pinned back from the undersige of the cup.

I think I used 3/16 pop rivets to hold the rollers back, while I put the armature in

From memory, it took a couple of goes, but it worked

Top of the page Bottom of the page
bbrasse1
Posted 2013-12-22 7:29 PM (#417898 - in reply to #417875)
Subject: Re: TF Overrunning Clutch Tool


Extreme Veteran

Posts: 537
50025
Location: Upstate NY		Let me know if you find one. I am doing the transmission next. Phil does a lot of transmission work. I wonder if he made one or has one?
Thanks
Top of the page Bottom of the page
Shep
Posted 2013-12-22 8:15 PM (#417902 - in reply to #417898)
Subject: Re: TF Overrunning Clutch Tool



Expert

Posts: 3470
200010001001001001002525
Location: Chestertown, NY ( near Lake George)		I made one up using the pics a model, used a wood base plate and cut the fingers out of sheet metal, used the sprag retainer as a template.
Top of the page Bottom of the page
Phil_the_frenchie
Posted 2013-12-23 4:14 AM (#417937 - in reply to #417898)
Subject: Re: TF Overrunning Clutch Tool



Elite Veteran

Posts: 927
50010010010010025
Location: Pau, S-W France
bbrasse1 - 2013-12-23 1:29 AM

Let me know if you find one. I am doing the transmission next. Phil does a lot of transmission work. I wonder if he made one or has one?
Thanks

Yes i've one and in metal !!!!! It's a guy who made it but you can use what you want as support. Here are old pics i can made new with extra dimensions (o.d diameter)



Edited by Phil_the_frenchie 2013-12-23 4:17 AM




(outil4.jpg)



(outil1.JPG)



Attachments
----------------
Attachments outil4.jpg (26KB - 318 downloads)
Attachments outil1.JPG (28KB - 322 downloads)
Top of the page Bottom of the page
57chizler
Posted 2013-12-23 2:51 PM (#418028 - in reply to #417937)
Subject: Re: TF Overrunning Clutch Tool



Expert

Posts: 3835
2000100050010010010025
Location: NorCal
Thanks, Phil. I've got a digital readout on my milling machine that can be programmed to drill multi-hole circle patterns...wanna give it a try one of these days.
Top of the page Bottom of the page
Phil_the_frenchie
Posted 2013-12-23 5:12 PM (#418060 - in reply to #417875)
Subject: Re: TF Overrunning Clutch Tool



Elite Veteran

Posts: 927
50010010010010025
Location: Pau, S-W France		ok but let me do better measurements (and pics !!) ... tomorrow !

Edited by Phil_the_frenchie 2013-12-23 5:14 PM
Top of the page Bottom of the page
57chizler
Posted 2013-12-24 3:24 PM (#418205 - in reply to #418060)
Subject: Re: TF Overrunning Clutch Tool



Expert

Posts: 3835
2000100050010010010025
Location: NorCal
OK, I managed to resurrect the engineering drawing I had.



(spragclutchtoolmodified.jpg)



Attachments
----------------
Attachments spragclutchtoolmodified.jpg (21KB - 342 downloads)
Top of the page Bottom of the page
ttotired
Posted 2013-12-24 4:46 PM (#418226 - in reply to #417875)
Subject: Re: TF Overrunning Clutch Tool



Expert 5K+

Posts: 8449
50002000100010010010010025
Location: Perth Australia		Thats very good

What is the pin leanth and I assume the diameter of the pins are the same as the holes around the outside of the disc?

Top of the page Bottom of the page
jboymechanic
Posted 2014-02-02 12:03 PM (#425481 - in reply to #417875)
Subject: Re: TF Overrunning Clutch Tool



Expert

Posts: 2216
2000100100
Location: Muskego, WI		That's my old drawing, glad it's been put to good use. I just used 3/16 rod I bought at Menards and pressed them into the hub that I made out of a big piece of delron. My pins were about 3.5 inches long and I rounded the heads to prevent any scratching to the sprag rollers.
Top of the page Bottom of the page
jaded13640
Posted 2020-10-26 5:04 PM (#604942 - in reply to #417875)
Subject: Re: TF Overrunning Clutch Tool



Veteran

Posts: 295
100100252525
Well thanks guys! I think I'm going to try the "nails in a piece of 2x4" method first. It's only gotta work once, if it does I'll keep it and hope it does again IF I ever need it again. I'm not lazy and I've even got a mill, lathe, set up plate etc, but all that stuff out in the building that DOESN'T have heat! LOL, the the wood and nails idea sound like it's worth a try, but I suspect I'll be firing up the mill tonight...in my mittens. Does your typical 3/16 drill bit leave enough meat to hold a piece of 3/16 rod stock?

Thanks,

Wayne

Edited by jaded13640 2020-10-26 5:14 PM
Top of the page Bottom of the page
